T/30P Geophysical and Geotechnical Seabed Survey

Closes 22 Apr 2020

Opened 23 Mar 2020

Overview

Beach Energy (Operations) Limited (Beach), propose to undertake a geophysical and geotechnical survey (site survey) over a portion of their T/30P permit and open acreage in the Otway Basin in Commonwealth waters. At its closest point, the site survey is approximately 76.5 km from the township of Port Campbell, Victoria.

The site survey is required to inform the location of future drilling of an exploration well and identify potential hazards.

The geophysical survey is required to obtain detailed bathymetry measurements and detect hazards on or below the seabed. Geophysical data will be acquired from the same vessel in two parts:

Geophysical survey to collect bathymetry data and detect hazards using the following: Multibeam echo sounder; Side-scan sonar; Sub-bottom profiler; Magnetometer; Ultra-Short Baseline Positioning System; and Sound Velocity Profiler and Conductivity, Temperature and Depth profiler.

High resolution two-dimensional shallow reflective imaging (2D survey) to inform shallow gas hazards. Equipment for this survey will consist of a sound source of up to 160 in3 and one 1.2 km streamer towed by a vessel at a speed of approximately 8-9 km/hr (4 – 5 knots).

The geotechnical survey is required to collect detailed information on the properties of the seabed and the underlying shallow sediments to build a picture of the local geology of the area and support geophysical data collected. The geotechnical survey, which may be undertaken from the same vessel as the geophysical and 2D survey or from a separate vessel, consists of: Coring; Piezo Cone Penetrometer Test; and Grab samples.

The site survey will take up to 28 days based on 21 days of survey time and 7 days for transits and setting up of equipment. Timings for each survey component is detailed below.

The site survey is proposed to be undertaken between 1 April 2020 and 31 December 2021. Timings of the survey is contingent on the availability of suitable vessels, weather and the receipt of required environmental approvals. The will be undertaken with only one vessel undertaking each component at a time:

• Geophysical survey – 7 days
• Geotechnical survey – 6 days
• 2D survey – 8 days

The survey area refers to the area where data acquisition will occur. This is a 6 km x 6 km area totalling 36 km2. The operational area refers to the area encompassing the survey area. It is where the geophysical and 2D survey vessel will run in and out to ensure there is a full coverage of the survey area and where the vessels will turn for the next survey line. This is a 10 km x 10 km area totalling 100 km2. Water depths across the operational area range from 150 m to 1,110 m.



Providing your comment

The public comment process provides an opportunity for community members to have their say on environmental management aspects of proposed oil and gas activities. To make a submission click on the link below.

If your comments contain sensitive information or if you are unable to use this platform for any reason please refer to our Public comment on environment plans brochure for alternative options to have your say.

Please be aware that information that is irrelevant to NOPSEMA’s decision making criteria cannot be considered, such as statements of fundamental objection to oil and gas activity, comments that contain personal threats or profanities, SPAM mail, comments made through online social media channels, petitions and comments that pose questions to NOPSEMA and or/the titleholder. NOPSEMA takes threats of a personal nature seriously and will consider legal action should the public comment process be misused to make personal threats to any NOPSEMA employee.
